N-Type 1F/3F 380-2500MHz wifi Signal Power Splitte

2-Way N-Type 1F/3F 380-2500MHz wifi Signal Power Splitter, RF-NY12

These 2 way N-Type 380-2500MHz Signal power splitter features 1 N-Type input and 3-N-Type outputs. Power splitter for Wifi/GSM/CDMA/3G/4G signals

Frequency range: 380MHz - 2500MHz
Input/Output Impedance: 50Ω
Connector: N-Type Female to 3 N-Type Female, (Outside Diameter: 6.25mm/0.25in)
Insertion loss: ≤3.1db/5.1db/6.1db
Input power: 50W/100W/200W
Input Voltage Standing Wave Ratio (VSWR): ≤1.4
VSWR: 1:1.3
Overall Dimensions: 3.5"x3.4"x1.1"
Weight: 5.5oz

Specifications:

• Input Connector: (1) N-Type Female
• output Connectors: (2) N-Type Female
• Input/Output Impedance: 50Ω
• Frequency range: 380MHz - 2500MHz
• Overall Dimensions: 3.5"x3.4"x1.1"

CablesOnline Part Number: RF-NY12
